Gravelbike

Unitraq

For those who really want something special. A gravelbike, handmade from ash wood.

Unique grain

We can promise you one thing: no frame will be the same. The grain of the wood always has its own identity, thanks to nature’s specialty.

Different packages

Depending on your requirements and looks, different packages are possible. A unique assembly is also possible.

Frame sizes

Basically, we offer you the next standard formats

Size 54 cm, 56 cm, 58 cm and 60 cm

To make your right decision based on your body, you can find the specific values of the frame parts. The letters refer to the illustration:

If you don’t know which size you should ride you can find some calculators on internet. But if you want professional advice, we refer you to a bike fitter for a personal measurement.
Or you test ride on different frames, however we might not have your size at the moment.

Part	Size 54 cm	Size 56 cm	Size 58 cm	Size 60 cm
A – Top tube	537	560	575	592
B – Reach	386	389	392	402
C – Seat tube	464	494	514	544
D – Headset	140	158	176	197
E – Stack	544	578	599	623
F – Chainstay	448	448	448	448
G – Height BB/hub	70	70	70	70
H – Wheelbase	1052	1051	1056	1068
I – Angle seattube	74.5	73.5	73	73
J – Angle headset	70	71.5	72	72.5

Silky smooth

Thanks to the special properties of wood, you will discover a completely new cycling experience. The wood itself absorbs the unevenness of the road.

Experience it yourself? It’s possible!

Riding art, flying start

Riding a wooden racing bike can be best described as riding on art. The fact that your bike is special will also be noticed by people around you.

Packages

Ready to make your cycling dream come true! Your own wooden road bike. We have put together some nice packages for you.

Or do you want something different? That’s possible as well!

Package A | Price on request*

Frame	Ash wood, hollow, thin-walled. Internal cable routing for the front derailleur, rear derailleur and rear brake. Aluminum BSA bottom bracket sleeve. Aluminum headset sleeve 44mm id Available in sizes 54cm, 56cm, 58cm and 60cm
Front fork	Moquai disc carbon standard black with internal brake line routing
Headset	Cane Creek 40-Series ZS44/28.6 – EC44/40
Stem	Ritchey Comp
Handlebar	Ritchey Comp
Seatpost	PRO Koryak 20mm offset 27.2mm
Saddle	PRO Turnix Performance Zwart 132mm
Wheels	FFWD Outride 30mm
Tyres	Vredestein Aventura Tricomp 44-622
Shifters**	Shimano GRX610
Brakes	Shimano GRX610 disc (flat mount)
Front derailleur**	None
Rear derailleur	Shimano GRX822 12-speed
Crankset	Shimano GRX610 12-speed
Cassette	Shimano CS-M7100 10-45 12-speed
Chain	Shimano CN-M7100
Bottom bracket	Shimano SM-BBR60

Package B | Price on request*

Frame	Ash wood, hollow, thin-walled. Internal cable routing for the front derailleur, rear derailleur and rear brake. Aluminum BSA bottom bracket sleeve. Aluminum headset sleeve 44mm id Available in sizes 54cm, 56cm, 58cm and 60cm
Front fork	Moquai disc carbon standard black with internal brake line routing
Headset	Cane Creek 40-Series ZS44/28.6 – EC44/40
Stem	PRO Discover 90mm
Handlebar	PRO Stuur Discover Alu 12 Graden Flare 44 cm 31.8 mm
Seatpost	PRO Discover carbon 27.2mm
Saddle	PRO Turnix Performance Zwart 132mm
Wheels	FFWD Tyro 45mm
Tyres	Vredestein Aventura Tricomp 44-622
Shifters**	Shimano GRX820
Brakes	Shimano GRX820 disc (flat mount)
Front derailleur**	None
Rear derailleur	Shimano GRX822 12-speed
Crankset	Shimano GRX820 12-speed
Cassette	Shimano CS-M8100 12-speed
Chain	Shimano CN-M8100 12-speed
Bottom bracket	Shimano SM-BBR60

Package C | Price on request*

Frame	Ash wood, hollow, thin-walled. Internal cable routing for the front derailleur, rear derailleur and rear brake. Aluminum BSA bottom bracket sleeve. Aluminum headset sleeve 44mm id Available in sizes 54cm, 56cm, 58cm and 60cm
Front fork	Moquai disc carbon standard black with internal brake line routing
Headset	Cane Creek 40-Series ZS44/28.6 – EC44/40
Stem	Ritchey WCS
Handlebar	Ritchey WCS
Zadelbuis	Ritchey Superlogic Carbon 27.2mm
Seatpost	PRO Turnix Performance Zwart 132mm
Wheels	Zipp 303S Firecrest 40mm
Tyres	Vredestein Aventura Tricomp 44-622
Shifters**	SRAM Red (electric)
Brakes	SRAM Red (flat mount)
Front derailleur**	SRAM Red (electric)
Rear derailleur	SRAM Red (electric)
Crankset	SRAM Red
Cassette	SRAM Red
Chain	SRAM Red
Bottom bracket	SRAM Dub BSA 68mm

Frameset | Price on request*

Frame	Essenhout hol dunwandig. Interne kabelgeleiding voor de voorderailleur, achterderailleur en achterrem. Aluminium BSA bottom bracket huls. Aluminium balhoofd huls 44mm id Leverbaar in de maten 54cm, 56cm en 58cm en 60cm
Front fork	Moquai disc carbon standard black with internal brake line routing
Headset	Cane Creek 40-Series ZS44/28.6 – EC44/40
Bottom bracket	Shimano BBR60

* Due to the continuously changing prices of bicycle parts, the valid price is on request. When you submit a request, we make a quote for you with a final price.
** You can also submit a request for a different assembly of the front derailleur (with or without).

Want to place an order?

I’m glad to meet you in the woods.

Sommige afbeeldingen zijn digitaal en kunnen afwijken van het echte product (houtnerfrichting en details).
Ook het frame en de onderdelen worden waar mogelijk verder verbeterd, waardoor uw (bestelde) houten fiets er anders uit kan zien.
